SPC Flooring Production Line

SPC flooring production line is a mechanical system for producing SPC flooring. The main materials of SPC floor are PVC resin and stone powder. During the production process, there is no need to add any glue or harmful chemical additives.

Send Inquiry

Product Introduction

The anti-wear speed of SPC floor produced by SPC flooring production line is about 8000RPM, and the anti-wear speed of wood floor is about 800RPM-4000RPM.

Features

1. Good anti-slip ability:

2. Flame retardant.

3. Waterproof and mildew proof.

4. Sound absorption.

5. Low shrinkage and warpage:

- SPC floor <0.1% after tempering

- SPC floor <0.25% before tempering

6. Easy to install, no connection gap.

Scope of Application

The surface wear-resistant layer has special anti-skid ability. When there is water on the surface, the anti-skid ability is enhanced, and people are not easy to slip. It is suitable for airports, hospitals, kindergartens and other public places with high requirements on the ground; it is widely used below SPC.

Specification

Product Name	SPC flooring	SPC flooring	SPC flooring
Product Width	1220MM	1220MM	1220MM
Product thickness	3-8MM	3-8MM	3-8MM
Output capacity	250-350KG/H	250-350KG/H
The above technical parameters is standard parameters, the actual parameters will be different according to different product.

Basic SPC Flooring Formula (Thickness 4mm)

No.	Name	Spec	Amount	Note
1	PVC resign	SG-5	100kg
2	CaCo3	300mesh, heavy type	300kg
3	Stabilizer	Calcium-Zinc	6kg
4	Lubricant	ZB74	0.8kg
5	Lubricant	PE-WAX	0.6kg
6	PA	ZB175, lubricant processing modifier	1kg
7	PA	ACR-401	3kg
8	PA	CPE-135A	6kg
9	Carbon black		3kg
10	Recycled materials	40-60 mesh	50kg
